Contact: Ronald P. Caster Phone: (951) 286-2053 / Email: sales@bansheeautoparts.com
"Use Back-Arrow to return from (Links Above)"
In Store Item's "Ready to Ship"
(The item's shown below are (upgrades) and (accessories) used with the "Banshee Supercharger" Kit.)
"SCT Products and Tuning Information is @ Bottom of the Page"
Banshee Supercharger Kit - designed specifically for 2001 & 2002 Ford Ranger 4.0 SOHC
"This kit is compatable with all Ford 4.0 SOHC vehicles but (may) require minor modifications"
"The Eaton M-90 Supercharger is (not) included in the Kit"
(The supercharger required is the 3rd generation m90, from the 1989 thru 1993 Ford T-Bird Supercoupe. (the inlet is oval))
 |
Sale Price $1595.00 plus $60.00 shipping 48-States
Banshee Fuelrail Kit - designed specifically for 2001 & 2002 Ford Ranger 4.0 SOHC
"This kit is compatable with all Ford 4.0 SOHC vehicles but (may) require minor modifications"
This Fuel Rail Kit will provide (equal) "volume & pressure to each fuel injector"
(This Fuel Rail Kit is (included) in the Supercharger Kit)
 |
Sale Price $527.00 plus $30.00 shipping 48-States
"Dual Pulley is needed when the (Supercharger Pulley) size is reduced"
 |
Sale Price $180.87 plus $16.00 shipping 48-States
Silicone Fittings
 |
 |
|
3" ID (76mm) Silicone 4mm wall / 3-layer 45deg (color-Blue) Sale Price $16.80 plus $6.00 shipping 48-States |
|
3" ID (76mm) Silicone 4mm wall / 3-layer 45deg (color-Black) Sale Price $16.80 plus $6.00 shipping 48-States |
Silicone Fittings
 |
 |
|
3" ID (76mm) Silicone 4mm wall / 3-layer Coup (color-Blue) Sale Price $8.10 plus $4.00 shipping 48-States |
|
3" ID (76mm) Silicone 4mm wall / 3-layer Coup (color-Black) Sale Price $8.10 plus $4.00 shipping 48-States |
Thin Wall Aluminum Tube Fittings
 |
 |
|
3" OD Aluminum Tube 45 deg Elbow Sale Price $22.25 plus $6.00 shipping 48-States |
|
3" OD Aluminum Tube 45 deg Elbow Sale Price $21.95 plus $6.00 shipping 48-States |
IAT Sensor is (required) when Boost is raised above 5.5 lbs
"Relocating IAT to discharge side of supercharger will allow (accurate) reading of the air temp that is entering the engine"
 |
 |
|
STANDARD AX3 IAT Sensor Sale Price $22.10 plus $3.00 shipping 48-States |
|
STANDARD S567 Sensor Connector Sale Price $20.23 plus $3.00 shipping 48-States |
BOSCH Fuel Injectors
"When raising Boost pressure above 5.5 lbs (increasing fuel injector) flow is required"
"Check with your installer to (verify) correct matching of the (injector & maf)"
 |
 |
|
BOSCH 0280155759 FUEL INJECTOR Set of (6) Injectors "Flow Matched from Bosch" 30lb with EV1 Connector Sale Price $359.92 plus $.00 shipping 48-States |
|
BOSCH 0280155868 FUEL INJECTOR Set of (6) Injectors "Flow Matched from Bosch" 36lb with EV1 Connector Sale Price $395.93 plus $.00 shipping 48-States |
BOSCH Fuel Injectors
"When raising Boost pressure above 5.5 lbs (increasing fuel injector) flow is required"
"Check with your installer to (verify) correct matching of the (injector & maf)"
 |
 |
|
BOSCH 0280155968 FUEL INJECTOR Set of (6) Injectors "Flow Matched from Bosch" 42lb with EV1 Connector Sale Price $392.40 plus $.00 shipping 48-States |
|
BOSCH 0280156127 FUEL INJECTOR Set of (6) Injectors "Flow Matched from Bosch" 39lb with EV6 Connector Sale Price $395.93 plus $.00 shipping 48-States |
BOSCH Fuel Injectors
"When raising Boost pressure above 5.5 lbs (increasing fuel injector) flow is required"
"Check with your installer to (verify) correct matching of the (injector & maf)"
BOSCH (0280150558) is used with the 80mm & 90mm MAF in the stock 1999 thru 2004 F-150 Lightning
Ford Racing (M-9593-M39) orighinal equipment in the 2003-2004 SVT Mustang
 |
 |
|
BOSCH 0280150558 FUEL INJECTOR Set of (6) Injectors "Flow Matched from Bosch" 42lb with EV1 Connector Sale Price $395.93 ea plus $.00 shipping 48-States |
|
FORD RACING M-9593-M39 FUEL INJECTOR 39lb with EV6 Connector Sale Price $45.00ea plus $3.00 shipping 48-States |
"Adapters Required (when) Injector & Connector are (not) Compatable"
 |
 |
|
EV1 CONNECTOR TO EV6 INJECTOR Sale Price $8.00ea plus $3.00 shipping 48-States |
|
EV6 CONNECTOR TO EV1 INJECTOR Sale Price $8.00ea plus $3.00 shipping 48-States |
BOSCH - Accessory Parts
 |
 |
|
FUEL INJECTOR O-RINGS Sale Price $3.00pair plus $1.00 shipping 48-States |
|
PIGTAIL TO EV1 INJECTOR Sale Price $8.00ea plus $1.00 shipping 48-States |
When increasing Boost above 6 lbs it will be necessary to increase MAF size to correspond to your injector selection.
80mm Lightning Air Meter (AXL3F-12B579-AA) is used in the 1999 thru 2000 F-150 Lightning Trucks - (42 lb Injectors / XL3V-A5A / 0280150558)
90mm Lightning Air Meter (M-12579-L54) is used in the 2001 thru 2004 F-150 Lightning Trucks - (42 lb Injectors / XL3V-A5A / 0280150558)
"Check with your installer to (verify) correct matching of the (injector & maf)" as (Requires recalibration for use on other vehicles)
 |
 |
|
80MM LIGHTNING AIR METER XL3F-12B579-AA Sale Price $170.00 plus $6.00 shipping 48-States |
|
90MM LIGHTNING AIR METER M-12579-L54 Stock replacement 90mm 2001 Sale Price $170.00 plus $6.00 shipping 48-States |
When increasing Boost above 6 lbs it will be necessary to increase MAF size to correspond to your injector selection.
80mm Ford Mustang GT Air Meter (YC2F-12B579-BA) is used in the 2002 Mustang GT - ( )
80mm Air Meter () is used in the Trucks - ()
"Check with your installer to (verify) correct matching of the (injector & maf)" as (Requires recalibration for use on other vehicles)
 |
 |
|
80MM 2002-MUSTANG GT AIR METER YC2F-12B579-BA Special Buy (while they last) $85.00 Sale Price $139.00 plus (Inc) shipping 48-States |
|
80MM AIR METER Y Sale Price $0.00 plus $0.00 shipping 48-States |
Top of the Line (2-1/16") Gauges by
(Link to Autometer Catalog)
"The (Fuel Pressure 1-100lb & Boost/Vacuum 30/30) are required with Boost "
NOTE! - "Fuel pressure gauge (must) be electrical and (not) mechanical" when installed within the cab area!
 |
 |
|
Autometer 4371 Fuel Pressure Gauge Sale Price $249.99ea plus Inc. shipping 48-States |
|
Autometer 4377 Boost/Vacuum Gauge Sale Price $229.34ea plus Inc shipping 48-States |
High Quality (white) Gauges by
(Link To
Glowshift Catalog)
"The (Fuel Pressure 1-100lb & Boost/Vacuum 30/30) are required with Boost "
NOTE! - "Fuel pressure gauge (must) be electrical and (not) mechanical" when installed within the cab area!
 |
 |
|
Glowshift GS-W701 Sale Price $42.99ea plus $.00 shipping 48-States List $110.99 |
|
Glowshift GS-W711 Sale Price $64.99ea plus $.00 shipping 48-States List $149.99 |
High Quality (black) Gauges by
(Link to
Glowshift Catalog)
"The (Fuel Pressure 1-100lb & Boost/Vacuum 30/30) are required with Boost "
NOTE! - "Fuel pressure gauge (must) be electrical and (not) mechanical" when installed within the cab area!
 |
 |
|
Glowshift GS-C701 Sale Price $42.99ea plus $.00 shipping 48-States List $110.99 |
|
Glowshift GS-C711 Sale Price $89.99ea plus $.00 shipping 48-States List $199.99 |
High Quality (white) Gauges by
(Link To
Glowshift Catalog)
"The (Fuel Pressure 1-100lb & Boost/Vacuum 30/30) are required with Boost "
NOTE! - "Fuel pressure gauge (must) be electrical and (not) mechanical" when installed within the cab area!
 |
 |
|
Glowshift GS-RD01 Sale Price $66.99ea plus $.00 shipping 48-States List $129.99 |
HERE
|
Glowshift GS-RD11 Sale Price $74.99ea plus $.00 shipping 48-States List $169.99 |
High Quality (black) Gauges by
(Link To
Glowshift Catalog)
"The (Fuel Pressure 1-100lb & Boost/Vacuum 30/30) are required with Boost "
NOTE! - "Fuel pressure gauge (must) be electrical and (not) mechanical" when installed within the cab area!
 |
 |
|
Glowshift GS-BD01 Sale Price $66.99ea plus $.00 shipping 48-States List $129.99 |
HERE
|
Glowshift GS-BD11 Sale Price $74.99ea plus $.00 shipping 48-States List $169.99 |
Ford Ranger GAUGE PODS by
(Link To Autometer
Catalog)
These Gauge Pods hold standard 2 1/16" gauge
 |
 |
|
Autometer 15308 Dual Pillar Pod Sale Price $30.99 plus (Inc) shipping 48-States |
|
Autometer 15309 Single Pillar Pod Sale Price $27.99 plus (Inc) shipping 48-States |
Ford Ranger GAUGE PODS by
(Link To
Glowshift Catalog)
Should be comparable with (most) Ford 4.0 SOHC Vehicles
These Gauge Pods hold standard 2 1/16" gauge
 |
|
|
Glowshift GS-249 Dual Pillar Pod Sale Price $16.99 plus (Inc) shipping 48-States List Price $49.99 |
|
B Sale Price $0.00 plus (Inc) shipping 48-States |
SCT Program Tuners available (direct) from www.Rogue Performance.com
Fred Sittmann has done hands on tuning of Banshee Supercharger customers with mail order tunes available.
Fred can also work with those that wish to (upgrade), or develop (custom) tunes for their specialized vehicles.
 |
 |
 |
 |
 |
 |
 |
 |
(Click the Part Number for Product Information)
|
SCT PROGRAMMER #1 Sale Price $.00 plus $.00 shipping 48-States |
SCT PROGRAMMER #2 Sale Price $.00 plus $.00 shipping 48-States |
